Image preview - the first page of the document



>> Download h-fs35100_training_manual documenatation <<

Text preview - extract from the document

                          H-FS35100
                     Component Repair
                  Service Training Manual                                                     Ver.1.0
                                                                                Internal use only




                    -S                                              -K
Specifications
INTERCHANGEABLE LENS FOR DIGITAL CAMERA
"LUMIX G VARIO 35-100 mm/F4.0-5.6 ASPH./MEGA O.I.S."
 Focal length                 f=35 mm to 100 mm
                                 (35 mm film camera equivalent: 70 mm to 200 mm)
Aperture type                    7 diaphragm blades/circular aperture diaphragm
Aperture range                   F4.0 (Wide) to F5.6 (Tele)
Minimum aperture value           F22
Lens construction                12 elements in 9 groups (1 aspherical lenses, 2 ED lenses)
In focus distance                0.9 m to
Maximum image magnification      0.11
