Image preview - the first page of the document



>> Download AR_DRI_P documenatation <<

Text preview - extract from the document

                                                          DRIVE C.B.A.
 Integrated Circuit   Capacitor              C2219       A-2    C2248          C-1      R2212        A-3   R2232      B-1
 IC2201     B-3       C2201       B-4        C2223       B-2    C2249          B-1      R2213        B-2   R2233      A-2
 IC2202     B-2       C2202       B-4        C2225       B-2    C2250          A-2      R2214        B-2   R2234      C-4
 IC2203     B-2       C2203       B-3        C2226       B-2    C2251          B-4      R2215        B-4   R2235      C-4
 IC2204     B-4       C2204       B-4        C2227       A-3    C2255          B-4      R2216        A-4   R2236      B-4
 IC2205     A-4       C2205       B-4        C2230       B-4    C2256          B-4      R2218        A-4   R2237      B-4
 IC2206     B-4       C2207       B-4        C2231       B-4    C2257          C-4      R2220        B-4   R2238      A-3
 IC2207     B-4       C2208       C-4        C2232       B-4    Resistor                R2221        B-4   R2250      A-4
 Transistor           C2209       C-3        C2233       B-4    R2201          B-4      R2222        A-4   Resistor Array
 Q2201      A-4       C2210       C-4        C2234       B-3    R2202          B-4      R2223        B-4   RA2201     B-2
 Q2202      B-4       C2211       B-3        C2235       C-1    R2204          B-4      R2224        B-4   RA2203     B-3
 Q2203      A-4       C2212       B-2        C2236       C-1    R2205          B-4      R2225        B-4
 Connector            C2213       B-2        C2237       B-1    R2207          C-4      R2226        A-4
 FP2002     B-1       C2214       B-2        C2239       A-4    R2208          C-3      R2227        B-4
 FP2003     C-1       C2215       A-2        C2240       B-4    R2209          C-3      R2228        B-4
 FP2004     C-4       C2217       B-2        C2246       B-4    R2210          B-4      R2229        B-4
 PS2001     A-3       C2218       B-2        C2247       B-1    R2211          B-4      R2231        A-2
ADDRESSINFORMATION




                NOTE:MULTILAYER C.B.A.
                   THIS C.B.A. IS Multi-Layer C.B.A. THIS CIRCUIT BOARD SHOWS COMPONENT LAYOUT-PATTERN
                   FOR COMPONENT SIDE AND FOIL SIDE. LAYOUT-PATTERNS ARE SINGLE PATTERN FOR EACH
                   SIDE THAT MAKE EASY TO SIGHT THE COMPONENT LAYOUT.




 C




 B




 A




                                         1                                                                  2               3   4
