>> Download Abp50e documenatation <<Text preview - extract from the document ORDER NO. AVS9908185C8
CCTV Camera
WV-BP50E
SPECIFICATIONS
Pick-up Device: 512 (H) x 582 (V) pixels, Interline Transfer CCD
Scanning Area: 4.8 (H) x 3.6 (V) mm (Equivalent to scanning area of 1/3"
pick-up tube)
Synchronization: Multiplexed vertical drive (VD2) by pulse from specified camera drive unit.
Scanning System: 2 : 1 interlace
Scanning: 625 lines / 50 fields / 25 frames
Horizontal: 15.625 kHz
Vertical: 50 Hz
Horizontal Resolution: 380 lines
Video Output: 1.15 V[p-p] composite 75
Signal-to-Noise Ratio: 46 dB (AGC OFF, weight ON)
Electronic Light Control: Equivalent to continuous variable shutter speed between 1/50 s
and 1/80 000 s
Minimum Illumination: 0.08 lx (0.008 foot-candle) at F1.4
Lens Mount: CS-mount
Ambient Operating Temperature: -10
