Image preview - the first page of the document
>> Download CQ-EN7160,61 documenatation <<
Text preview - extract from the document
ORDER No.2015
AUTOMOTIVE ELECTRONICS
NISSAN
CQ-EN7160Z
CQ-EN7161Z
AM/FM MPX ELECTRONIC TUNING
RADIO and RDS with 6-Disc CD
Changer
NISSAN PART No. 28185 7Z900 (CQ-EN7160Z)
NISSAN PART No. 28185 7Z960 (CQ-EN7161Z)
ID CORD : PY110 (CQ-EN7160Z)
ID CORD : PY350 (CQ-EN7161Z)
VEHICLE : Xterra/ EX-Cab Frontier
DESTINATION : North America
PRODUCED AFTER : Aug., 2001
Specifications*
General
Power Supply DC 12V (11V - 16V), IDC (6-Disc Indash CD Changer)
Test Voltage 13.2V Signal to Noise Ratio More than 65dB (IHF-A)
Negative Ground Total Harmonic Distortion Less than 0.4%
Current Consumption Less than 3.0A Channel Separation More than 65dB (IHF-A)
(at Illumination: ON)
