Image preview - the first page of the document
cy130101


>> Download cy130101 documenatation <<

Text preview - extract from the document
T1150-3 STOP            T1150-5 STOP            T1150-7 STOP             T1150-14 STOP            T1150-16 STOP
190Vp-p (5msec.div.)    500Vp-p (5usec.div.)    36Vp-p (5usec.div.)      100Vp-p (5usec.div.)     1.8Vp-p (5usec.div.)




T1150-17 STOP           T1150-18 STOP           T1150-19 STOP            T1150-20 STOP            IC6001-20 PAUSE
2.2Vp-p (5usec.div.)    3.4Vp-p (5usec.div.)    5.2Vp-p (5usec.div.)     125Vp-p (5usec.div.)     4.4Vp-p (10msec.div.)




IC6001-21 REC           IC6001-24 REC           IC6001-61 REC            IC6001-68 REC            IC6001-89 REC
4.4Vp-p (10msec.div.)   4.4Vp-p (10msec.div.)   2.0Vp-p (10usec.div.)    4.4Vp-p (10msec.div.)    4.6Vp-p (10msec.div.)




IC6001-90,91 REC        IC6001-93,94 FF/REW     IC6001-97,98 REC         IC6001-99 REC            IC6001-100 REC
5.2Vp-p (10msec.div.)   5.0Vp-p (1msec.div.)    4.8Vp-p (10msec.div.)    4.8Vp-p (10msec.div.)    4.8Vp-p (10msec.div.)




IC6001-107 REC          IC6001-111,112 REC      IC6001-114 PLAY          IC2501-1,18,20 REC       IC3001-2 REC
5.0Vp-p (10msec.div.)   6.0Vp-p (10msec.div.)   4.2Vp-p (10msec.div.)    8.4Vp-p (5msec.div.)     1.2Vp-p (5msec.div.)




IC3001-4 PLAY           IC3001-14 REC           IC3001-15 PLAY           IC3001-20 PLAY           IC3001-24 REC/PLAY
5.0Vp-p (5msec.div.)    0.4Vp-p (20usec.div.)   0.5Vp-p (20usec.div.)    150mVp-p (20usec.div.)   4.7Vp-p (10msec.div.)




IC3001-37 REC/PLAY      IC3001-38 REC/PLAY      IC3001-42,43 PLAY        IC3001-48,50 REC         IC3001-52 REC/PLAY
4.8Vp-p (5msec.div.)    4.6Vp-p (5msec.div.)    0.4Vp-p (5msec.div.)     1.2Vp-p (5msec.div.)     2.4Vp-p (5msec.div.)




IC3001-78 REC/PLAY      IC4501-9,14 REC         IC4501-21 REC           IC4501-53,57 REC/PLAY     IC3501-1 REC/PLAY
1.2Vp-p (5msec.div.)    1.2Vp-p (5msec.div.)    1.2Vp-p (5msec.div.)    1.2Vp-p (5msec.div.)      4.6Vp-p (10msec.div.)
