Image preview - the first page of the document
>> Download cy16if_f documenatation <<
Text preview - extract from the document
(VEP06E76A)
DVD INTERFACE C.B.A.
Transistor
Q33001 B-4
Q33002 B-4
Q33003 C-4
Q33004 D-4
F Q33005 D-4
Q33006 D-4
Q33007 D-4
Q33008 D-4
Q33012 B-4
Q34003 C-7
Q34004 A-8
Q34005 A-7
Q36001 B-2
Q36002 E-6
Q36003 E-2
Transistor & Resistor
QR34001 C-5
QR34004 B-7
QR34005 B-7
E QR34006 C-5
QR36001 B-2
QR36002 B-2
QR36003 B-2
Integrated Circuit
IC31002 E-6
IC31003 C-6
IC34001 C-6
IC34002 B-7
IC36001 D-2
IC36002 D-3
Connector
TL36004 C-2
TL36005 B-2
D TL36006 C-2
TL36008 TL36007 C-2
TL36008 D-2
ADDRESS INFORMATION
C
TL36004
TL36006
TL36007
TL36005
B
A
(FOIL SIDE) NV-VHD1B/EC/EE/F DVD INTERFACE C.B.A.
1 2 3 4 5 6 7 8
