Image preview - the first page of the document
>> Download cy16powr documenatation <<
Text preview - extract from the document
IMPORTANT SAFETY NOTICE:
COMPONENTS IDENTIFIED WITH THE MARK HAVE THE SPECIAL CHARACTERISTICS FOR SAFETY.
WHEN REPLACING ANY OF THESE COMPONENTS, USE ONLY THE SAME TYPE.
THE STRIPED FRAME INDICATES THE PRIMARY CIRCUIT TO DISTINGUISH THE PRIMARY
CAUTION FROM THE SECONDARY CIRCUIT.
PAY ATTENTION NOT TO RECEIVE AN ELECTRIC SHOCK DURING REPAIR AND SERVICE OF
THE PRODUCTS.
POWER C.B.A.
Transistor
Q1200 B-3
Q1150 B-4
Q1151 C-4
Q1152 C-4
Q1153 B-3
Integrated Circuit
IC1200 A-1
Connector
P1101 D-1
P1102 B-4
P1103 A-1
ADDRESS INFORMATION
(VEP019911A)
D
LB1214
C
R1230
LB1218
R1290
B
R1240
R1201
R1200 R1210
R1203 R1205
R1209
R1202 R1206
R1204
A
NV-VHD1B/EC/EE/F
POWER C.B.A.
1 2 3 4 5
