G
TV DEMODULATOR PACK PCB
Transistor
Q0702 A-3
Integrated Circuit
IC0701 E-3
Adjustment
T0701 C-4
VR0701 E-2
VEP07A23S: NV-VP25EC, NV-VP30EC Connector
PK0701 A-2
F VEP07A23T: NV-VP30EB PP0701 C-1
VEP07A23U: NV-VP30EBL, NV-VP30EP ADDRESS INFORMA TION
E
D
C
B
A NV-VP25EC
NV-VP30EC/EB/EBL/EP
TV DEMODULATOR PACK PCB
SOLDER SIDE
1 2 3 4 5
