Image preview - the first page of the document
rcp9001w


>> Download rcp9001w documenatation <<

Text preview - extract from the document
T001-B1 STOP           T001-P1 STOP           T001-P2 STOP           T001-S3 STOP
60Vp-p (5 sec.div)     500Vp-p (5 sec.div)    20Vp-p (5m sec.div)    50Vp-p (5 sec.div)




T001-S2,S4 STOP        IC001-2 STOP           IC001-4 STOP           P7402-2 REC/PLAY
24Vp-p (5 sec.div)     1.0Vp-p (5 sec.div)    1.0Vp-p (5 sec.div)    1.0Vp-p (20 sec.div)




P7402-18 REC/PLAY      P7402-22 REC/PLAY      P7402-26 REC/PLAY      P7402-30 REC/PLAY
0.8Vp-p (20 sec.div)   1.0Vp-p (20 sec.div)   1.0Vp-p (20 sec.div)   0.6Vp-p (20 sec.div)




P7402-34 REC/PLAY      P7402-48,50 REC/PLAY   PP7401-16 REC/PLAY     PP7401-18 REC/PLAY
0.6Vp-p (20 sec.div)   0.8Vp-p (1m sec.div)   1.2Vp-p (20 sec.div)   1.2Vp-p (20 sec.div)




PP7401-20 REC/PLAY
2.0Vp-p (20 sec.div)
