Image preview - the first page of the document
wf


>> Download wf documenatation <<

Text preview - extract from the document
T1150-3 STOP           T1150-5 STOP           T1150-7 STOP           T1150-15,18 STOP
30Vp-p (5 sec.div)     560Vp-p (5 sec.div)    8Vp-p (5m sec.div)     30Vp-p (5 sec.div)




IC1150-1 STOP          IC1150-2 STOP          P7402-83 REC/PLAY      P7402-51 REC/PLAY
8.0Vp-p (5 sec.div)    0.5Vp-p (5 sec.div)    1.0Vp-p (20 sec.div)   0.7Vp-p (20 sec.div)




P7402-47 REC/PLAY      P7402-59 REC/PLAY      P7402-63 REC/PLAY      P7402-55 REC/PLAY
1.0Vp-p (20 sec.div)   1.0Vp-p (20 sec.div)   0.6Vp-p (20 sec.div)   0.6Vp-p (20 sec.div)




P7402-29,31 REC/PLAY   JK3903-2 REC/PLAY      JK3903-3 REC/PLAY      JK3903-4 REC/PLAY
0.8Vp-p (1m sec.div)   1.1Vp-p (20 sec.div)   1.1Vp-p (20 sec.div)   2.0Vp-p (20 sec.div)
