Image preview - the first page of the document
031327398625276SHR


>> Download 031327398625276SHR documenatation <<

Text preview - extract from the document
                     For Authorised Service Agents Only
                                                                               Ref No:      031327398625276SHR

                                                                               Date:              05/10/2009
     TECHNICAL INFORMATION                                                                  Created by
                                                                                    Panasonic UK - Service Group

Document Category:           Knowledge Base


Subject:                     FAULT CODES

Model(s) Affected:           DMR-EX75EB       DMR-EX85EB

Problem / Issue              No tuning, disc draw opening , U80, U61, U81, U61 OR HDDERR fault codes
                             show.

Solution:                    Please check for damaged PCB, please see attached pictures.

                             ALSO ENSURE XTAL X7502 (ON TOP SURFACE OF DIGITAL/IF PCB-UNDER
                             HDD BRACKET) LEGS HAVE NOT BEEN SHORTED TOGETHER BY THE
                             BRACKET LANDING ON TOP OF THE XTAL-SEE ATTACHMENT

                             straighten the legs and lay the xtal flat on the PCB




            Confidential                            Page 1               031327398625276SHRREV
