>> Download DMR-EX85EB deel2 documenatation <<Text preview - extract from the document For Authorised Service Agents Only
Ref No: 031327398625276SHR
Date: 05/10/2009
TECHNICAL INFORMATION Created by
Panasonic UK - Service Group
Document Category: Knowledge Base
Subject: FAULT CODES
Model(s) Affected: DMR-EX75EB DMR-EX85EB
Problem / Issue No tuning, disc draw opening , U80, U61, U81, U61 OR HDDERR fault codes
show.
Solution: Please check for damaged PCB, please see attached pictures.
ALSO ENSURE XTAL X7502 (ON TOP SURFACE OF DIGITAL/IF PCB-UNDER
HDD BRACKET) LEGS HAVE NOT BEEN SHORTED TOGETHER BY THE
BRACKET LANDING ON TOP OF THE XTAL-SEE ATTACHMENT
straighten the legs and lay the xtal flat on the PCB
Confidential Page 1 031327398625276SHRREV
