Image preview - the first page of the document



>> Download w_01 documenatation <<

Text preview - extract from the document

T1150-3 STOP             T1150-5 STOP             T1150-7 STOP             T1150-13 STOP           T1150-17 STOP
3.8Vp-p (2msec.div.)     560Vp-p (5usec.div.)     33Vp-p (5usec.div.)      76Vp-p (5usec.div.)     18Vp-p (5usec.div.)




T1150-19 STOP            T1150-20 STOP            Q1200-1 STOP             IC2501-22,23,25 PLAY    IC6001-13 STILL
40Vp-p (5usec.div.)      100Vp-p (5usec.div.)     0.4Vp-p (5usec.div.)     7.0Vp-p (2msec.div.)    5.0Vp-p (5msec.div.)




IC6001-18 REC            IC6001-50 REC/PLAY       IC6001-52 REC/PLAY       IC6001-68,69 REC        IC6001-70 REC
5.0Vp-p (10msec.div.)    2.0Vp-p (20usec.div.)    2.0Vp-p (20usec.div.)    5.0Vp-p (5msec.div.)    5.0Vp-p (5msec.div.)




IC6001-71 REC            IC6001-72 REC            IC6001-79,80 FF/REW      IC6001-90 REC           IC6001-94,95 REC
5.0Vp-p (5usec.div.)     5.0Vp-p (5msec.div.)     5.0Vp-p (1msec.div.)     5.0Vp-p (10msec.div.)   6.8Vp-p (10msec.div.)




IC6001-97 PLAY           IC3001-6 REC/PLAY        IC3001-17,21 REC         IC3001-26 REC           IC3001-29 REC/PLAY
0.8Vp-p (10msec.div.)    0.8Vp-p (0.5msec.div.)   1.0Vp-p (20
