Image preview - the first page of the document
>> Download PSG1003006CE_PRINTDB documenatation <<Text preview - extract from the document PSG1003006CE
Blu-ray Disc Home Theater Sound System
Model No. SA-BT230EB
SA-BT230EE
SA-BT230EG
SA-BT230EP
SA-BT330EB
SA-BT330EG
SA-BT330EP
Volume 1
Product Color: (K)...Black Type
Notes: 1) These model's BD Drive/Main P.C.B. Assembly are:-
- RFKNBT230EBA (For BT230EB);
- RFKNBT230EGA (For BT230EG);
- RFKNBT230EPA (For BT230EP);
- RFKNBT230EEA (For BT230EE);
- RFKNBT330EBA (For BT330EB);
- RFKNBT330EGA (For BT330EG);
- RFKNBT330EPA (For BT330EP).
2) Please refer to the original service manual for:
