Image preview - the first page of the document
>> Download p_all_01 documenatation <<
Text preview - extract from the document
A DVD MODULE P.C.B. (SIDE:A)
A DVD MODULE P.C.B.
(SIDE:A)
F
Transistors
Q8550 B-3
Transistor-resistors
QR8571 B-4
Integrated Circuits
IC8051 E-6
IC8251 B-6
IC8651 D-6
Connectors
FP8031 E-4
E
FP8101 F-4
FP8421 C-1
FP8451 F-2
ADDRESS INFORMATION
D
C
B
A
(REP3679H-C ... SA-HT623 (GCS, GCU))
SA-HT623(EE,GCS,GCU)/SA-HT888(GCA)
(REP3679L-C ... SA-HT623 (EE) / SA-HT888 (GCA))
DVD MODULE P.C.B. (SIDE:A)
1 2 3 4 5 6 7
A DVD MODULE P.C.B. (SIDE:B) *IC8611 is not supplied in the form of an individual part.
When replacing, be sure to replace the module p.c.b. and not IC8611 singly. A DVD MODULE P.C.B.
(SIDE:B)
Transistors
F Q8551 B-5
Q8552 B-5
Q8560 B-5
Q8561 B-5
Q8562 B-5
Transistor-resistors
QR8431 D-6
Integrated Circuits
IC8001 D-3
IC8111 F-3
E IC8451 E-6
IC8601 B-2
IC8611 C-1
Connectors
FP8251 B-3
FP8501 A-4
ADDRESS INFORMATION
D
C
B
A
SA-HT623(EE,GCS,GCU)/SA-HT888(GCA)
DVD MODULE P.C.B. (SIDE:B)
1 2 3 4 5 6 7
