Image preview - the first page of the document



>> Download CFS-B5LMK2 documenatation <<

Text preview - extract from the document

                                               CFS-B5LMK2
  SERVICE MANUAL                                                                  East European Model
  Ver 1.0 1999. 05




                                                                 Model Name Using Similar Mechanism                 NEW
                                                                 Tape Transport Mechanism Type                      MF-B5MK2-117




                                               SPECIFICATIONS

  Frequency range                                      Battery life
       FM: 65.0 - 108 MHz                                   FM recording
       MW: 531 - 1,602 kHz
                                                            Sony R20P: approx. 16 hours
       LW: 153 - 279 kHz
       SW: 5.95 - 18 MHz                                    Sony LR20 alkaline: approx. 36 hours
  Aerials                                                   Playback
       FM/SW: Telescopic antenna                            Sony R20P: approx. 8 hours
       MW/LW: Built-in ferrite bar                          Sony LR20 alkaline: approx. 21 hours
  Recording system
       4-track, 2-channel stereo                       Power requirements
  Frequency response                                       230 V AC, 50 Hz
       70 - 10,000 Hz                                      9 V DC, six R20 (size D) batteries
  Speakers                                             Power consumption
       Full range: 10 cm (4 inches) dia.,                  AC 14 W
       2.8 ohms cone type
