Image preview - the first page of the document
>> Download D-E440_X documenatation <<
Text preview - extract from the document
D-E440/E441/E441SR/E443/E445/
E446CK/E449CK
SERVICE MANUAL US Model
D-E441/E445/E446CK/E449CK
Ver 1.0 1999.02
Canadian Model
D-E441/E445/E446CK
AEP Model
D-E440/E441/E441SR/E443/E445/E446CK
UK Model
D-E441/E441SR/E443/E445/E446CK
E Model
D-E441/E443/E445/E446CK
Australian Model
D-E441/E445/E446CK
Photo : D-E441
Chinese Model
D-E441/E445
Model Name Using Similar Mechanism NEW
CD Mechanism Type CDM-2811EAA
Optical Pick-up Type DAX-11E
SPECIFICATIONS
CD player General Dimensions (w/h/d) (without projecting parts and
System Power requirements controls)
Compact disc digital audio system For the area code of the model you purchased, Approx. 129 x 28 x 146 mm
Laser diode properties check the upper left side of the bar code on the ( 51/8 x 11/8 x 53/4 in.)
Material: GaAIAs package. Mass (without rechargeable battery)
