Image preview - the first page of the document
>> Download cx-jn3_193 documenatation <<
Text preview - extract from the document
CX-JN3
SERVICE MANUAL US Model
AEP Model
Ver. 1.2 2005.05
UK Model
E Model
CX-JN3 is the amplifier, CD player, tape deck
and tuner section in JAX-N3/PK3.
Model Name Using Similar Mechanism NEW
CDM74-K6BD71A, CDM74S-K6BD71A,
CD Mechanism Type
CDM74S-K6BD72
CD
Section Base Unit Name BU-K6BD71A, BU-K6BD72
Optical Block Name KSM-213DCP
Optical Pick-up Name KSS-213D
Tape deck Model Name Using Similar Mechanism NEW
Section Tape Transport Mechanism Type CWM43FF13, CWM43FF25
SPECIFICATIONS
TUNER CASSETTE DECK GENERAL
FM tuning range 87.5 MHz to 108 MHz Track format 4 tracks, 2 channels stereo Power requirements 120 V AC, 60 Hz
FM usable sensitivity (IHF) 13.2 dBf Frequency response 50 Hz ◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
