Image preview - the first page of the document



>> Download d-fj210_fj215 documenatation <<

Text preview - extract from the document

                                                       D-FJ210/FJ215
SERVICE MANUAL                                                                                                                  US Model
                                                                                                                                                D-FJ210
Ver 1.0 2003.02                                                                                                          E Model
                                                                                                                Australian Model
                                                                                                                 Chinese Model
                                                                                                                                                D-FJ215




                                                                   Photo : D-FJ210


                                                                                       Model Name Using Similar Mechanism            D-EJ360
                                                                                       CD Mechanism Type                             CDM-3325ER
                                                                                       Optical Pick-up Type                          DAX-25E
                        SPECIFICATIONS
System                                                                        Power requirements
Compact disc digital audio system                                             For the area code of the model you purchased, check the upper left side of
Laser diode properties                                                        the bar code on the package.
Material: GaAlAs
