Image preview - the first page of the document



>> Download hcd-vx3a documenatation <<

Text preview - extract from the document

                                                                             HCD-VX3A
  SERVICE MANUAL                                                                                                            E Model
                                                                                                                       Tourist Model




  HCD-VX3A is the Amplifier, CD player,
  Tape Deck and Tuner section in MHC-VX3.


  Manufactured under license from Dolby Laboratories                       Model Name Using Similar Mechanism HCD-VX5A/VX5AJ/VX7A
  Licensing Corporation.
                                                     CD                    CD Mechanism Type                            CDM38L-5BD34L
  "DOLBY" and the double-D symbol a are trademarks
  of Dolby Laboratories Licensing Corporation.       Section               Base Unit Name                               BU-5BD34L
                                                                           Optical Pick-up Name                         KSS-213D/Q-RP
                                                                Tape deck Model Name Using Similar Mechanism HCD-GRX30
                                                                Section    Tape Transport Mechanism Type                TCM-230AWR2/230PWR2


                                                                SPECIFICATIONS
  Amplifier section                                                       Laser output                Max. 44.6
