HCD-VX90AV
SERVICE MANUAL E Model
HCD-VX90AV is the tuner, deck, CD and
amplifier section in MHC-VX90AV.
Model Name Using Similar Mechanism HCD-GRX80/RXD8/RXD8S
CD CD Mechanism Type CDM38L-5BD34L
SECTION
Base Unit Type BU-5BD34L
Optical Pick-up Type KSS-213D/Q-NP
TAPE DECK Model Name Using Similar Mechanism HCD-GRX80/RXD8/RXD8S
SECTION Tape Transport Mechanism Type TCM-230AWR2/230PWR2
SPECIFICATIONS
-- Continued on next page --
COMPACT DISC DECK RECEIVER
