Image preview - the first page of the document



>> Download hcd-h331_h331d_102 documenatation <<

Text preview - extract from the document

                                 HCD-H331/H331D
  SERVICE MANUAL                                                                                                                   US Model
                                                                                                                                   HCD-H331/H331D

                                                                                                                     Canadian Model
                                                                                                                             E Model
                                                                                                                    Australian Model
                                                                                                                                            HCD-H331




  r   HCD-H331/H331D is the tuner, deck,
      CD and amplifier section in MHC-331,
      MHC-D2, MHC-G33.

                                                                    Photo : HCD-H331


                                                                                     Model Name Using Similar Mechanism           HCD-H881/H881D
  Dolby noise reduction manufactured under license from                CD
  Dolby Laboratories Licensing Corporation.                                          CD Mechanism Type                             CDM38-5BD19
  "DOLBY" and the double-D symbol a are trademarks of                  Section
                                                                                     Base Unit Name                                   BU-5BD19
  Dolby Laboratories Licensing Corporation.
                                                                       Tape deck     Model Name Using Similar Mechanism                 NEW
                                                                       Section       Tape Transport Mechanism Type                TCM-YSW47C24

                                                                     SPECIFICATIONS
   AUDIO POWER SPECIFICATIONS                         FM tuner section                                   Intermediate frequency
   POWER OUTPUT AND TOTAL                             Tuning range US, Canadian model :                                450kHz
   HARMONIC DISTORTION :                                                87.5 - 108MHz (100kHz step)
   with 6 ohm loads, both channels driven,                              EXCEPT US, Canadian model :      Amplifier section
   from 40-20kHz ; rated 100 watts per                                  87.5 - 108MHz (50kHz step)       US, Canadian model :
   channel minimum RMS power, with no                 Antenna       FM lead antenna                       FTC 100W+100W (8ohm, 40-20kHz, 0.9% THD)
   more then 0.9 % total harmonic distortion          Antenna terminals                                   Continuous RMS power output
   from 250 milliwatts to rated output.                             75 ohm unbalanced                            120W + 120W (8 ohm, 1kHz, 5% THD)
                                                      Intermediate frequency                             EXCEPT US, Canadian model :
   CD player section                                                10.7 MHz                              Peak music power output
   System         Compact disc and digital audio                                                                400W
                  system                                AM tuner section                                  Continuous RMS power output
   Laser          Semiconductor laser                   Tuning range                                             20W + 20W (6 ohm, 1kHz, 10% THD)
   Laser output Max 44.6
