Image preview - the first page of the document
>> Download hcd_rxd8s_153 documenatation <<
Text preview - extract from the document
HCD-GRX80/RXD8/RXD8S
SERVICE MANUAL AEP Model
HCD-RXD8/RXD8S
UK Model
HCD-RXD8
E Model
Australian Model
HCD-GRX80
HCD-GRX80/RXD8/RXD8S is the
tuner, deck, CD and amplifier section
in MHC-GRX80/RXD8/RXD8S. Photo: HCD-RXD8 (SILVER)
Model Name Using Similar Mechanism HCD-GRX8/R800/RX88/RX99
CD CD Mechanism Type CDM38LH-5BD32L
SECTION
Base Unit Type BU-5BD32L
Optical Pick-up Type KSS-213D/Q-N
TAPE DECK Model Name Using Similar Mechanism HCD-GRX8/R800/RX88/RX99
SECTION Tape Transport Mechanism Type TCM-230AWR1/230PWR1
SPECIFICATIONS
-- Continued on next page --
COMPACT DISC DECK RECEIVER
