Image preview - the first page of the document
>> Download sony_icf-703l_sm documenatation <<
Text preview - extract from the document
ICF-703/703L
SERVICE MANUAL AEP Model
ICF-703/703L
Ver 1.0 2000. 03 UK Model
ICF-703L
(Photo: ICF-703L (BLACK))
SPECIFICATIONS
Frequency range:
Italy
Band ICF-703 ICF-703L
FM 87.5 - 108.0 MHz --
AM 526.5 - 1606.5 kHz --
Other countries
Band ICF-703 ICF-703L
FM 87.5 - 108.0 MHz 87.5 - 108.0 MHz
SW -- --
AM (MW) 530 - 1605 kHz 530 - 1605 kHz
LW -- 153 - 255 kHz
Speaker
Approx. 10.2 cm (4 1/8 inches) dia. 8 ohms
Power output
430 mW (at 10 % harmonic distortion)
Output
v jack (◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
