Image preview - the first page of the document
>> Download GLP22M TX-32LMD70A TX-32LMD70FA TX-32LMD71FA TX-32LMD72FA TX-26LMD70A TX-26LMD70FA TX-26LMD71FA documenatation <<
Text preview - extract from the document
ORDER No. PCZ0709109CE
Service Manual
Colour LCD Television
TX-32LMD70A
TX-32LMD70FA
TX-32LMD71FA
TX-32LMD72FA
TX-26LMD70A
TX-26LMD70FA
TX-26LMD71FA
GLP22M Chassis
Specifications
(Informations in brackets [ ] refers to model 26")
Power Source: 220-240V AC, 50Hz
Power Consumption 135W [104W]
Stand-by Power Consumption: 1.0W (TV ONLY)
13W (TV+DVB set to record)
Aerial Impedance: 75 unbalanced, Coaxial Type
Receiving System: LMD70A LMD70FA
PAL-I PAL-I/H, B/G, D/K
PAL-525/60 (AV only) SECAM B/G, D/K, L/L'
DVB (via UHF aerial input) PAL-525/60 (AV only)
M.NTSC (AV only) DVB (via VHF/UHF aerial input)
NTSC (AV only) M.NTSC (AV only)
NTSC (AV only)
Receiving Channels: LMD70A LMD70FA
UHF E21-E68 VHF E2-E12 VHF H1-H2 (ITALY)
VHF A-H (ITALY) VHF R1-R2
VHF R3-R5 VHF R6-R12
UHF E21-E69 CATV (S01-S05)
CATV S1-S10 (M1-M10) CATV S11-S20 (U1-U10)
CATV S21-S41 (Hyperband)
Operating Conditions: Temperature: 0◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
