Image preview - the first page of the document
>> Download GLP23A TX-32LE8F TX-32LE8FS TX-32LE8L TX-32LE8P TX-32LE8PS documenatation <<
Text preview - extract from the document
ORDER No. PCZ0805037CE
Service Manual
Colour LCD Television
TX-32LE8F
TX-32LE8FS
TX-32LE8L
TX-32LE8P
TX-32LE8PS
GLP23A Chassis
Specifications
Power Source: 220-240V AC, 50Hz
Power Consumption 121W
Stand-by Power Consumption: 1W
Aerial Impedance: 75 unbalanced, Coaxial Type
Receiving System: PAL-I/H, B/G, D/K,
SECAM B/G, D/K, L/L'
PAL-525/60 (AV only)
M.NTSC (AV only)
NTSC (AV only)
Receiving Channels: VHF E2-E12 VHF H1-H2 (ITALY)
VHF A-H (ITALY) VHF R1-R2
VHF R3-R5 VHF R6-R12
UHF E21-E69 CATV (S01-S05)
CATV S1-S10 (M1-M10) CATV S11-S20 (U1-U10)
CATV S21-S41 (Hyperband)
Operating Conditions: Temperature: 0◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
