Confidential
For Authorised Service Agents Only Ref No: MQM0133DG041215REV2
TECHNICAL INFORMATION
A BG CY E FL I LT MD NL S TR Date
AL BIH CZ EST GB IRL LV MK P SK UA 01/12/2015
AND BY D F GR IS M MNE PL SLO Country Reported
B CH DK FIN H L MC N RO SRB Europe
Product Category: LCD TV / LCD IDTV
Subject: Distorted sound
Model(s) Affected: TX-39/42A400B TX-39/42AS500B TX-39/42AW404 TX-42AS520Y
TX-39/42A400E TX-39/42AS500E TX-42AS520B TX-39/42ASW504
TX-39/42A400Y TX-39/42AS500Y TX-42AS520E
Symptom / Distorted sound
Cause:
Remedy / Replace both speakers with ones with a date code from 15th August 2015 onwards: *5H15
Method: Please use the original part number L0EYAA000052
Year Month Day
Date code
Warranty Claims - Please use the following IRIS and Activity codes
Activity Codes: Guarantee Code Activity Location Stock Indicator
(UK Only) A R W D
Symptom Section Defect
Condition Repair
IRIS Codes: Area Type Code Area Code Area Code
1 3 3 16A 1 LCD 71 D A
Note: Failure to use the correct IRIS and Activity codes may result in the claim being rejected
Document No: MQM_TI
Panasonic 1 of 1 Rev: 12.00 DG110612
