Image preview - the first page of the document



>> Download LA02 TX-L42D25B TX-L42D26B documenatation <<

Text preview - extract from the document

                                                                                                  ORDER No. PCZ1004053CE




Service Manual
                                                               Colour LCD Television
                                                                                                TX-L42D25B
                                                                                                TX-L42D26B


                                                                                            LA02 Chassis
Specifications

   Power Source:                 220-240V AC, 50/60Hz

   Power Consumption             152W

   Stand-by Power Consumption: 0.30W (Without monitor out recording)
                               36W (With monitor out recording)

   Aerial Impedance:             75 unbalanced, Coaxial Type

   Receiving System:             PAL-I
                                 PAL-525/60 (AV only)
                                 DVB-T/T2 Digital terrestrial services via UHF aerial input.
                                 DVB-S/S2
