Image preview - the first page of the document
>> Download LA03 TC-L37U22X Different Points documenatation <<
Text preview - extract from the document
ORDER NO.MTNC100217AE
37 inch Class 1080p LCD HDTV
Model No. TC-L37U22X
LA03 Chassis
Please file and use this manual together with the service manual for Model No.
TC-L37U22, ORDER NO. MTNC100209CE.
1 Different points
1.1. Mechanical Replacement Parts List
Ref. No. Parts No. Parts name & Description Pcs Remarks
TC-L37U22 TC-L37U22X
THEJ024 THEJ024 SCREW(A-L2/A-S2/FLM8/P-S1/BTM1) 14 16pcs 14pcs
THTD020J THTD020J SCREW(A-PRINT:4) 10 12pcs 10pcs
TXJA110QGM TXJA040QGN SPEAKER LEAD 1 PAVCA
TXFK04XSER TXFKP05XSER SIDE AV BRACKET 1 PAVCA
----- TMME378 CLAMPER (P2) 2
14 TMX2AE009 ----- BRACKET-IP -
15 TQB2AA0568 TQB2AC0003 INSTRUCTION BOOK 1 PAVCA
18 TXFKY010QGM TXFKY010QGN CABINET ASSY 1 PAVCA
1.2. Electrical Replacement Parts List
Ref. No. Parts No. Parts name & Description Pcs Remarks
TC-L37U22 TC-L37U22X
PCB TXN/A10QGMS TXN/A10QGNS CIRCUIT BOARD A 1 (RTL) PAVCA
PCB TXN/V10QMMS TXN/V10QMMM CIRCUIT BOARD V 1 (RTL) PAVCA
IC8004 TVRR296S TVRR339S IC 1 PAVCA
IC8503 TVRR303S TVRR347AAS IC 1 PAVCA
JS1000 D0GAR00Z0001 ----- C 0 OHM, 0.063W 1
JS1003 ----- D0GAR00Z0001 C 0 OHM, 0.063W 1
