Image preview - the first page of the document
>> Download LH64 TX-32LX70F TX-32LX70L TX-32LX70P TX-26LX70F TX-26LX70L TX-26LX70P documenatation <<
Text preview - extract from the document
ORDER No. PCZ0702011CE
ISSUE 2
Service Manual
Colour LCD Television
TX-32LX70F
TX-32LX70L
TX-32LX70P
TX-26LX70F
TX-26LX70L
TX-26LX70P
LH64 Chassis
Specifications
(Informations in brackets [ ] refers to model 26")
Power Source: 220-240V AC, 50/60Hz
Power Consumption 134W [100W]
Stand-by Power Consumption: 0.4W
Aerial Impedance: 75 unbalanced, Coaxial Type
Receiving System: LX70L LX70F, LX70P
PAL-I, PAL-I/H, B/G, D/K,
PAL-525/60 (AV only) SECAM B/G, D/K, L/L'
M.NTSC (AV only) PAL-525/60 (AV only)
NTSC (AV only) M.NTSC (AV only)
NTSC (AV only)
Receiving Channels: LX70L LX70F, LX70P
UHF E21-E68 VHF E2-E12 VHF H1-H2 (ITALY)
VHF A-H (ITALY) VHF R1-R2
VHF R3-R5 VHF R6-R12
UHF E21-E69 CATV (S01-S05)
CATV S1-S10 (M1-M10) CATV S11-S20 (U1-U10)
CATV S21-S41 (Hyperband)
Operating Conditions: Temperature: 0◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
