Image preview - the first page of the document
>> Download LH69 TX-19LED8F TX-19LED8FS TX-19LXD8 documenatation <<
Text preview - extract from the document
ORDER No. PCZ0809175CE
Service Manual
Colour LCD Television
TX-19LED8F
TX-19LED8FS
TX-19LXD8
LH69 Chassis
Specifications
Power Source: 220-240V AC, 50/60Hz
Power Consumption 57W
Stand-by Power Consumption: 0.5W (Without monitor out recording)
19W (With monitor out recording)
Aerial Impedance: 75 unbalanced, Coaxial Type
Receiving System: LXD8 LED8F
PAL-I, PAL-I/H, B/G, D/K,
PAL-525/60 (AV only) SECAM B/G, D/K, L/L'
DVB (via UHF aerial input) PAL-525/60 (AV only)
M.NTSC (AV only) DVB (via VHF/UHF aerial input)
NTSC (AV only) M.NTSC (AV only)
NTSC (AV only)
Receiving Channels: LXD8 LED8F
UHF E21-E68 VHF E2-E12 VHF H1-H2 (ITALY)
VHF A-H (ITALY) VHF R1-R2
VHF R3-R5 VHF R6-R12
UHF E21-E69 CATV (S01-S05)
CATV S1-S10 (M1-M10) CATV S11-S20 (U1-U10)
CATV S21-S41 (Hyperband)
Operating Conditions: Temperature: 0◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
