Service Manuals, User Guides, Schematic Diagrams or docs for : panasonic LCD LH32G TC-20LA5 TC-20LE5

<< Back | Home

Most service manuals and schematics are PDF files, so You will need Adobre Acrobat Reader to view : Acrobat Download Some of the files are DjVu format. Readers and resources available here : DjVu Resources
For the compressed files, most common are zip and rar. Please, extract files with Your favorite compression software ( WinZip, WinRAR ... ) before viewing. If a document has multiple parts, You should download all, before extracting.
Good luck. Repair on Your own risk. Make sure You know what You are doing.



Image preview - the first page of the document
LH32G TC-20LA5 TC-20LE5


>> Download LH32G TC-20LA5 TC-20LE5 documenatation <<

Text preview - extract from the document
                                                                                         ORDER NO. ITD0503008CE
                                                                                               B05    Canada:B07




                                                                                                     LCD TV
                                                  TC-20LA5
                                                  TC-20LE5
                                                  LH32G Chassis




Specifications
      Power Source           AC 120 V, 60 Hz
      Power Consumption      Average use : 56 W
                             Stand-by condition : 0.11 W
                             Power off : 0.10 W
      LCD                    20-inch (510 mm), 4 : 3 aspect ratio LCD panel
      Screen Size            16.06 " (408.0 mm) (W)
