Image preview - the first page of the document
LR11 TH-32LR11UK TH-32LR11UH


>> Download LR11 TH-32LR11UK TH-32LR11UH documenatation <<

Text preview - extract from the document
                                                                                                                   Order Number MTNC080864CE
                                                                                                                               B34 Canada: D10




                                                                 High Definition Hospitality LCD Display
                                                                              Model No. TH-32LR11UK
                                                                                                TH-32LR11UH
                                                                              LR11 Chassis




TABLE OF CONTENTS
                                                                    PAGE                                                                      PAGE
 1 Safety Precautions----------------------------------------------- 3             8.1. Removal of Rear Cover -------------------------------- 18
     1.1. General Guidelines---------------------------------------- 3             8.2. Removal of Pedestal Assy----------------------------- 18
 2 Warning -------------------------------------------------------------- 4        8.3. Removal of AC Cord ------------------------------------ 18
     2.1. Prevention of Electrostatic Discharge (ESD)                              8.4. Removal of Slot Block ---------------------------------- 18
          to Electrostatically Sensitive (ES) Devices---------- 4                  8.5. Removal of HX-Board----------------------------------- 19
     2.2. About lead free solder (PbF)---------------------------- 5               8.6. Removal of DS-Board----------------------------------- 19
 3 Service Navigation ----------------------------------------------- 6            8.7. Removal of Control Panel Assy ---------------------- 20
     3.1. Service Hint ------------------------------------------------- 6         8.8. Removal of DN-Board ---------------------------------- 20
     3.2. Applicable signals ----------------------------------------- 7           8.9. Removal of P-Board------------------------------------- 20
 4 Specifications ----------------------------------------------------- 8        8.10. Removal of S-Board------------------------------------- 21
 5 Operating Instructions------------------------------------------ 9             8.11. Removal of V-Board ------------------------------------- 21
 6 Service Mode -----------------------------------------------------11          8.12. Removal of Speaker (L, R) ---------------------------- 21
     6.1. CAT (Computer Aided Test) mode ------------------- 11                  8.13. Removal of LCD Panel and Cabinet ---------------- 21
     6.2. IIC mode structure (following items value is                         9 Block Diagram --------------------------------------------------- 23
          sample data) -----------------------------------------------14           9.1. Block (1 of 5) Diagram ---------------------------------- 23
 7 Troubleshooting Guide ----------------------------------------15                9.2. Block (2 of 5) Diagram ---------------------------------- 24
     7.1. Self Check--------------------------------------------------15           9.3. Block (3 of 5) Diagram ---------------------------------- 25
     7.2. No Power ---------------------------------------------------17           9.4. Block (4 of 5) Diagram ---------------------------------- 26
     7.3. No Picture --------------------------------------------------17          9.5. Block (5 of 5) Diagram ---------------------------------- 27
 8 Disassembly and Assembly Instructions ---------------18                    10 Wiring Connection Diagram--------------------------------- 29
