LV1M TC-15DT2


>> Download LV1M TC-15DT2 documenatation <<

Text preview - extract from the document
                                                                                                              ORDER NO. ITD0011014C1
                                                                                                                                 B05




                                                             Combination 15.2" LCD TV/DVD Player
                                                                     TC-15DT2
                                                                     LV1M Chassis




Power Source                                                                 8cm double-sided, single-layer
         AC 120V, 60Hz                                                   COMPACT disc (CD-DA, VIDEO CD)
Power Consumption                                                            12cm disc
         Average use: 54.2W (Maximum Current 3.62A)                          8cm disc
         Stand-by condition: 0.45 W                                  Accessories Supplied
LCD                                                                          Remote control Transmitter
         TFT 15.2-inch, 16:9 aspect ratio, 854 x 480 dots, 409.920           TNQE262
         pixel                                                               AAA (R03) Battery x 2
Screen Size                                                          Operating Conditions
         13.19" (335mm)(W) x 7.4" (188mm)(H) x 15.12"(384mm)                 Temperature: 34
