Image preview - the first page of the document
>> Download SL-115P TX-17LX2 TX-17LX2F documenatation <<Text preview - extract from the document DSL115PEF0
Service Manual
LCD TV
CHASSIS : SL-115P
MODEL : TX-17LX2(UK)
TX-17LX2F(EUROPE)
Power Source NTSC (AV input only)
"AC 100-240V, 50/60Hz" Playback From NTSC video
Power Consumption recorders (VCR)
Average use : 50W
Stand-by condition : 3w Aerial-ear
"TV set DC 15v, 1.2A max" UHF(UK only)/VHF
LCD Operating Conditions
"17-inch(434.38mm), 15:9 Temperature : 5-35
