Image preview - the first page of the document



>> Download th-65lfe8_sm documenatation <<

Text preview - extract from the document

                                                                                                                 ORDER NO. VED1505558CE




                                                          TH-65LFE8J                  (65V  )

                                                          TH-55LFE8J                  (55V  )

                                                          TH-48LFE8J                  (48V  )             FULL HD LCD Display
                                                          TH-43LFE8J                  (43V  )

                                                                         Model No.             TH-65LFE8U
                                                                                               TH-65LFE8W
                                                                                               TH-65LFE8E








3  7


TH-43LFE8J43V    TH-48LFE8J48V
E8J55V TH-65LFE8J65V




                                                                          WARNING
       This service information is designed for experienced repair technicians only and is not designed for use by the general public.
                                                                            Q41G42M103713B
       It dose not contain warnings or cautions to advise non-technical individuals of potential dangers in attempting to service a product.
       Products powered by electricity should be serviced or repaired only by experienced professional technicians. Any attempt to ser-
       vice or repair the product or products dealt with in this service information by anyone else could result in serious injury or death.



                                                      IMPORTANT SAFETY NOTICE
      There are special components used in this equipment which are important for safety. These parts are marked by 7 in the schematic
      diagram, circuit board diagrams, exploded views and replacement parts list. It is essential that these critical parts should be replaced
      with manufacturer's specified parts to prevent shock, fire, or other hazards. Do not modify the original design without permission of
      manufacturer.
