Image preview - the first page of the document
>> Download panasonic_th-l50b6z_chassis_km21 documenatation <<
Text preview - extract from the document
ORDER NO. MTV1301099CE
LED TV
Model No. TH-L50B6Z
Chassis: KM21
Destination: NEW ZEALAND
TABLE OF CONTENTS
PAGE PAGE
1 Safety Precautions----------------------------------------------- 3 5.1.7. Hotel Mode Adjustment ---------------------------- 10
1.1. General Guidelines---------------------------------------- 3 5.1.8. Hotel Mode-------------------------------------------- 10
1.1.1. Leakage Current Cold Check---------------------- 3 6 Troubleshooting Guide --------------------------------------- 11
1.1.2. Leakage Current Hot Check (See Figure 6.1. Check of the IIC bus lines------------------------------ 11
1.) --------------------------------------------------------- 3 6.1.1. How to access --------------------------------------- 11
2 Warning -------------------------------------------------------------- 4 6.1.2. Exit ------------------------------------------------------ 11
2.1. Prevention of Electrostatic Discharge (ESD) 6.2. Power LED Blinking timing chart --------------------- 12
to Electrostatically Sensitive (ES) Devices---------- 4 6.3. No Power--------------------------------------------------- 12
2.2. About lead free solder (PbF)---------------------------- 5 7 Disassembly and Assembly Instructions--------------- 13
3 Service Navigation ----------------------------------------------- 6 7.1. Speaker Bracket ----------------------------------------- 13
3.1. Service Hint ------------------------------------------------- 6 7.2. LCD Panel Assembly ----------------------------------- 14
4 Specifications ----------------------------------------------------- 7 7.3. LCD Panel Fixing & Handling Method -------------- 15
5 Service Mode ------------------------------------------------------ 8 7.4. LED Panel and Bracket Ass'y------------------------- 16
5.1. How to enter into Service Modes ---------------------- 8 7.5. Vesa Metal ------------------------------------------------- 17
5.1.1. Contents of adjustment mode --------------------- 8 7.6. Side Metal Bracket--------------------------------------- 18
5.1.2. How to exit---------------------------------------------- 8 7.7. Metal Bracket 1 ------------------------------------------- 19
5.1.3. Display of SOS History ------------------------------ 9 7.8. Metal Bracket 2 ------------------------------------------- 20
5.1.4. POWER ON TIME/COUNT ------------------------ 9 7.9. Metal Bracket Bottom ---------------------------------- 21
5.1.5. Exit-------------------------------------------------------- 9 7.10. PCB Installation ------------------------------------------ 22
5.1.6. Self Check Mode-------------------------------------10 7.11. Pedestal Ass'y 1------------------------------------------ 23
