Image preview - the first page of the document
543961664023440BR


>> Download 543961664023440BR documenatation <<

Text preview - extract from the document
                     For Authorised Service Agents Only
                                                                               Ref No:      543961664023440BR


                                                                              Date:             16/10/09
   TECHNICAL INFORMATION                                                                 Created by
                                                                                 Panasonic UK - Service Group

Document Category:           Knowledge Base


Subject:                     Stuck in s/by with a single flash of LED. (inverter SOS)

Model(s) Affected:            TX-32LMD70A

Problem / Issue              Stuck in s/by with a single flash of the LED (inverter SOS)

Solution:                    Fault was traced to a trapped wire that had eventually broken through the insulation
                             and was arcing to chassis. The LCD panel was replaced.




            Confidential                              Page 1                       543961664023440BRREV1
