Image preview - the first page of the document
689516594255223BR


>> Download 689516594255223BR documenatation <<

Text preview - extract from the document
                     For Authorised Service Agents Only
                                                                              Ref No:     689516594255223BR

                                                                              Date:            07/10/09
   TECHNICAL INFORMATION                                                                Created by
                                                                                Panasonic UK - Service Group

Document Category:           Knowledge Base


Subject:                     No power up, led flashing continually & rapidly and relay dropping in/out every 4
                             seconds.

Model(s) Affected:           TX-26LXD60       TX-32LXD60

Problem / Issue              No power up, led flashing continually & rapidly and relay dropping in/out every 4
                             seconds.

Solution:                    All the supply rails were coming up to the correct levels as the relay pulled in.
                             Further checks in the PSU revealed that Q803 and D804 were both short circuit.
                             A replacement P pcb cured the problem.




            Confidential                             Page 1                    689516594255223BRREV1
