Image preview - the first page of the document



>> Download LCD_Pedestal_Stand_Fitting documenatation <<

Text preview - extract from the document

                                                               Support


DOCUMENT TITLE      Fitting Pedestal Stand to LCD Television

APPLICABLE MODELS   All Models
                                                                Support



Supplied Parts of the pedestal stand




                               Balbir Rahelu




                                       Example taken from the TX-L32E30B
                              Support




Screw `A' Counter-sunk head
Support
                                                                         Support



1) The fixing slot for the stand is located on the bottom of the unit.




2006 LCD Model                                                 2011 LCD Model

                                   Stand slot location
                                                 Support



Inserting the Stand into the Television




2006 LCD Model                            2011 LCD MODEL
                                                        Support



Using a cross-headed screw-driver tighten the screws.
