ORDER NO.PCZ0603023TE
Technical Information
LCD Television
TX-32LX60L, TX-32LXD60, TX-26LX60L, TX-26LXD60
Chassis: GLP21
Subject: The Ticking Noise within Standby Mode.
Warning
This service information is designed for experienced repair technicians only and is not designed for use by the general public. It does not contain warnings or
cautions to advise non-technical individuals of potencial dangers in attempting to service a product. Products powered by electricity should be serviced or
repaired only by experienced professional technicians. Any attempt to service or repair the product or products deal within this service information by anyone
else could result in serious injury or death.
Symptom: The Ticking Noise audible while TV is within Standby Mode.
When making a claim please the following IRIS codes:
Condition code = C Defect code = Y
Symptom code = 140 Repair code = I
Remedy: Change the resistor R838.
Component Before alteration After alteration Placement
R838 ERJ6GEYJ104V/100k ERJ6GEYJ103V/10k P - board
