Image preview - the first page of the document
>> Download TX-32LXD60 documenatation <<
Text preview - extract from the document
For Authorised Service Agents Only
Ref No: 201666284343953BR
Date: 09/10/09
TECHNICAL INFORMATION Created by
Panasonic UK - Service Group
Document Category: Knowledge Base
Subject: The entire lower half (50%) of the screen freezes up with half an image while the
top half is normal.
Model(s) Affected: TX-26LXD60 TX-32LXD60
Problem / Issue The entire lower half (50%) of the screen freezes up with half an image top half is
normal, the picture is the entire field of the channel being displayed but is
compressed, this appears to be a signal processing problem.
Some times there may be dashed white lines over the picture before it splits into
two. See picture below.
Solution: All Video processing and AV selection is performed by IC1501.This fault is caused
by dry joints on IC1501. Please reflow the solder on IC1501
Confidential Page 1 201666284343953BRREV1
