Image preview - the first page of the document
>> Download PCZ0810185AE documenatation <<
Text preview - extract from the document
ORDER No. PCZ0810185AE
Service Manual
Colour LCD Television
TX-32LXD86FV
TX-37LXD86FV
GLP23H Chassis
NOTE:
This manual should be used in conjunction with the Service Manual for
the model TX-32LXD85F, TX-37LXD85F (PCZ0804034CE).
Specifications
(Informations in brackets [ ] refers to model 32")
Power Source: 220-240V AC, 50Hz
Power Consumption 180W [140W]
Stand-by Power Consumption: 0.4W (Without monitor out recording)
15W (With monitor out recording)
Aerial Impedance: 75 unbalanced, Coaxial Type
Receiving System: PAL-I/H, B/G, D/K
SECAM B/G, D/K, L/L'
PAL-525/60 (AV only)
DVB (via VHF/UHF aerial input)
M.NTSC (AV only)
NTSC (AV only)
Receiving Channels: VHF E2-E12 VHF H1-H2 (ITALY)
VHF A-H (ITALY) VHF R1-R2
VHF R3-R5 VHF R6-R12
UHF E21-E69 CATV (S01-S05)
CATV S1-S10 (M1-M10) CATV S11-S20 (U1-U10)
CATV S21-S41 (Hyperband)
Operating Conditions: Temperature: 0◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
