       Confidential

                  For Authorised Service Agents Only                                   Ref No: MQM0132AH011215REV1


       TECHNICAL INFORMATION
 A     BG         CY         E          FL         I   LT            MD           NL      S            TR           Date
 AL    BIH        CZ         EST        GB        IRL  LV            MK            P      SK           UA        01.12.2015
AND    BY         D          F          GR        IS  M              MNE          PL      SLO             Country Reported
 B     CH         DK         FIN         H        L  MC              N            RO      SRB                 Europe
Product Category:             LCD TV / LCD IDTV

Subject:                      Black Spots


Model(s) Affected:            TX-55CXW404
                              TX-55CX400


Symptom /                 Black spots / shades are visible on the screen.
Cause:

Remedy / If black spots similar to the example below are visible on the screen, note the model number and
Method: productcode, then order and replace the Panel. Please see the picture below for an example.



                                                                         Fig. 1: Model number




                                                                           Fig. 2: Productcode




                                                   Fig. 3: Example


Warranty Claims - Please use the following IRIS and Activity codes
      Activity Codes:        Guarantee Code         Activity        Location      Stock Indicator
            (UK Only)              A                  R                W                 D
                                        Symptom                    Section                Defect
                Condition                                                                              Repair
IRIS Codes:                      Area     Type     Code        Area       Code     Area         Code
                      1           3          3      16A         1         LCD       71          D        A
Note: Failure to use the correct IRIS and Activity codes may result in the claim being rejected
