Image preview - the first page of the document
>> Download PCZ1007122CE documenatation <<
Text preview - extract from the document
ORDER No. PCZ1007122CE
REVISION 2
Service Manual
Colour LCD Television
TX-L19D28BP
TX-L19D28BW
TX-L19D28EP
TX-L19D28EW
GLP25 Chassis
Specifications
Power Source: 220-240V AC, 50Hz
Rated Power Consumption: 39W
Stand-by Power Consumption: 0.3W (Without monitor out recording)
13W (With monitor out recording)
Aerial Impedance: 75 unbalanced, Coaxial Type
Receiving System: L19D28B
PAL-I
PAL-525/60 (AV only)
M.NTSC (AV only)
NTSC (AV only)
DVB-T Digital terrestrial services via UHF aerial input .
L19D28E
PAL-I/H, B/G, D/K,
SECAM B/G, D/K, L/L'
PAL-525/60 (AV only)
M.NTSC (AV only)
NTSC (AV only)
DVB-T Digital terrestrial services (MPEG2 and MPEG4-AVC(H.264))
DVB-C Digital cable services (MPEG2 and MPEG4-AVC(H.264))
Receiving Chanels: L19D28B L19D28E
UHF E21-E68 VHF E2-E12 VHF H1-H2 (ITALY)
VHF A-H (ITALY) VHF R1-R2
VHF R3-R5 VHF R6-R12
UHF E21-E69 CATV (S01-S05)
CATV S1-S10 (M1-M10) CATV S11-S20 (U1-U10)
CATV S21-S41 (Hyperband)
Aerial - Rear: L19D28B L19D28E
UHF VHF/UHF
Operating Conditions: Temperature: 0◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
