Image preview - the first page of the document
TX-L26C20ES


>> Download TX-L26C20ES documenatation <<

Text preview - extract from the document
     Confidential
                    For Authorised Service Agents Only                                Ref No: MQM0040CM100610REV1


TECHNICAL INFORMATION
A        BY         D        EST        H        IS       N            PL        SK        UA        Date       10/06/2010
AL       CH         DK        F          I        L       NL           RO       SLO        FIN           Country Reported
B        CZ          E       GB        IRL       LT       P             S        TR                         Germany
Product Category:             LCD Television / LCD IDTV

Subject:                     Abnormally loud high-pitched noise from the P-PCB


Model(s) Affected:           TX-L26C20E               TX-L26C20ES               TX-L26C20B                    (Chassis:GLP25)




Symptom /                Abnormally loud high-pitched oscillation noise from the P-PCB.
Cause:                   This problem can occur on rare occasions due to certain combinations of the component
                         tolerances.


Remedy / The issue can be improved by changing R871 on the P-PCB (Part No: TNP0EP015AA)
Method: to 2.7k, 0.5W. (Part Number: ERDS1TJ272T)


        R871                                                            R871




     NOTE: This Technical Information applies to units prior to serial number N*-0311001
          This information does not apply to units after this serial number.




Warranty Claims - Please use the following IRIS and Activity codes                          Please note: This is a Field Service
      Activity Codes:       Guarantee Status     Repair Type        Location    Source        activity and is reflected by the
                                                                                                      Activity Code - S
            (UK Only)              A                  S                F          D
                                       Symptom                     Section              Defect
                Condition                                                                              Repair
IRIS Codes:                     Area    Type      Code     Area          Code    Area        Code
                     1           1        4           5        1         PSU      2              N        i
Note: Failure to use the correct IRIS and Activity codes may result in the claim being rejected


                                                                                                         Document No: MQM_TI
     Panasonic                                            1 of 1                                           Rev: 1.00 GM210710
