Image preview - the first page of the document
>> Download PCZ1203036AE documenatation <<
Text preview - extract from the document
ORDER No. PCZ1203036AE
Service Manual
LCD Television
TX-L37ETS51
LA35 Chassis
NOTE:
This manual should be used in conjunction with the Service Manual
for the model TX-L37ETW5 (PCZ1202003CE).
Warning
This service information is designed for experienced repair technicians only and is not designed for use by the general public. It does not
contain warnings or cautions to advise non-technical individuals of potencial dangers in attempting to service a product. Products
powered by electricity should be serviced or repaired only by experienced professional technicians. Any attempt to service or repair the
product or products deal within this service information by anyone else could result in serious injury or death.
DIFFERENCE LIST
Description TX-L37ETW5 TX-L37ETS51
IC8902 /PEAKS EEP/ X24CL37ETW5 X24CL37ETS51
A P.C.B. A-L37ETW5 A-L37ETS51
REMOTE CONTROL N2QAYB000752 N2QAYB000572
BATTERY COVER OF RC BAT-C-0752 BAT-C-0572
CABINET ASSY TXFKY01UJUE TXFKY01VDUE
MODEL LABEL TBM0E09862 TBM0E09872
INSTRUCTION BOOKS:
GERMAN TQB0E2210A TQB0E2218A
ITALIAN TQB0E2210C TQB0E2218C
FRENCH TQB0E2210D TQB0E2218D
CZECH TQB0E2210R -
