Image preview - the first page of the document
>> Download PCZ1102012CE documenatation <<
Text preview - extract from the document
ORDER No. PCZ1102012CE
REVISION 2
Service Manual
LCD Television
TX-L32EW30
TX-L37EW30
TX-L32EW30S
TX-L37EW30S
LA18 Chassis
Specifications
(Information in brackets [ ] refers to model 32")
Power Source: 220-240V AC, 50 / 60Hz
Rated Power Consumption: 100W [87W]
Stand-by Power Consumption: 0.3W (Without monitor out recording)
29W (With monitor out recording)
Aerial Impedance: 75 unbalanced, Coaxial Type
Receiving System: DVB-T (Digital Terrestrial Services (MPEG2 and MPEG4-AVC(H.264))
DVB-C (Digital cable services (MPEG2 and MPEG4-AVC(H.264))
DVB-S/S2 (Digital satellite services (MPEG2 and MPEG4-AVC(H.264))
