Image preview - the first page of the document
>> Download PCZ1005059CE documenatation <<
Text preview - extract from the document
ORDER No. PCZ1005059CE
REVISION 2
Service Manual
Colour LCD Television
TX-L32G20E
TX-L32G20ES
TX-LF32G20S
TX-L37G20E
TX-L37G20ES
TX-LF37G20S
GLP25 Chassis
Specifications
(Information in brackets [ ] refers to model 32")
Power Source: 220-240V AC, 50Hz
Rated Power Consumption: 150W [103W]
Stand-by Power Consumption: 0.25W (Without monitor out recording)
15W [19W] (With monitor out recording)
Aerial Impedance: 75 unbalanced, Coaxial Type
Receiving System: PAL-I/H, B/G, D/K
SECAM B/G, D/K, L/L'
PAL-525/60 (AV only)
DVB-T (Digital Terrestrial Services (MPEG2 and MPEG4-AVC(H.264))
DVB-C (Digital cable services (MPEG2 and MPEG4-AVC(H.264))
M.NTSC (AV only)
NTSC (AV only)
PC signals: VGA, SVGA, WVGA, XGA, SXGA, WXGA (compressed)
