PCZ1102013CE


>> Download PCZ1102013CE documenatation <<

Text preview - extract from the document
                                                                                              ORDER No. PCZ1102013CE




Service Manual
                                                                                 LCD Television

                                                                                            TX-L32C3B




                                                                           GLP26 Chassis

Specifications
  Power Source:               220-240V AC, 50Hz
  Rated Power Consumption:    90W
  Stand-by Power Consumption: 0.3W (Without monitor out recording)
                              10.3W (With monitor out recording)
  Aerial Impedance:             75 unbalanced, Coaxial Type
  Receiving System:             C3B (UK)
                                DVB-T/T2 Digital terrestrial services via UHF aerial input (MPEG2 and MPEG4-AVC(H.264))
                                PAL-I
                                PAL-525/60 (AV only)
                                M.NTSC (AV only)
                                NTSC (AV only)

                                C3B (Ireland)
                                DVB-T Digital terrestrial services (MPEG2 and MPEG4-AVC(H.264))
                                PAL-I
                                PAL-525/60 (AV only)
                                M.NTSC (AV only)
                                NTSC (AV only)



  Receiving Channels:           C3B (UK)                   C3B (Ireland)
                                UHF E21-E68                VHF A-J              UHF E21-E69
                                                           CATV S1-S20          CATV S21-S41 (Hyperband)

  Operating Conditions:         Temperature: 0
